[#270] Added a patched 'environment_indicator_navigation' submodule showing the environment on the Navigation sidebar. by AlexSkrypnyk · Pull Request #274 · drevops/website

AlexSkrypnyk · 2026-07-30T07:21:45Z

Closes #270

Checklist before requesting a review

Subject includes ticket number as [#123] Verb in past tense.
Ticket number #123 added to description
Added context in Changed section
Self-reviewed code and commented in commented complex areas.
Added tests for fix/feature.
Relevant tests run and passed locally.

Changed

The environment indicator was invisible on every page. Uninstalling toolbar (Enable core Navigation module #255) made ToolbarHandler::externalIntegration('toolbar') return FALSE, so environment_indicator_page_top() fell back to rendering its classic full-width strip as the first element of <body>. That strip is position: static; z-index: 10, while core Navigation's sidebar (fixed, z-index: 501) and top bar (fixed, z-index: 490) both sit at top: 0. Measured as uid 1 at 1280px, document.elementFromPoint(640, 5) returned ASIDE.top-bar - the strip was painted underneath the navigation chrome on both the front-end and admin themes, so no viewport position exposed it.
It also cost 28px of dead layout. The strip stayed in document flow while being invisible, pushing every authenticated page down. On the homepage .ct-header sat at 92px; with the strip gone it returns to 64px, flush under the top bar.
Added patches/environment-indicator-navigation.patch, which creates an environment_indicator_navigation submodule inside drupal/environment_indicator. The submodule shows the active environment as an 8px coloured stripe along the inline-start edge of the Navigation sidebar - the treatment the parent module already applies to Gin's vertical toolbar via border-left on .toolbar-menu-administration. It depends on environment_indicator and navigation, so no defensive module guards are needed.
Targeted .admin-toolbar, which is core Navigation's class - defined in core/modules/navigation/layouts/navigation.html.twig, not the contrib admin_toolbar module, which is uninstalled and whose assets never load. Core sets border-inline-end on that element but never border-inline-start, and Gin only sets top and height, so the property is unclaimed and needs no specificity override. The sidebar is box-sizing: border-box, so it stays exactly 265px wide and Drupal.displace() offsets are untouched.
Namespaced the width property deliberately. The parent module defines --environment-indicator-border-width: 6px at :root in CSS that is still attached, so reusing that name would silently yield 6px. The submodule uses --environment-indicator-navigation-width, defaulting to 8px, and --environment-indicator-navigation-color for the colour.
Registered the patch in composer.json, patches.lock.json (via composer patches-relock, recorded at depth: 1) and config/default/core.extension.yml. Because the patch only adds files, it applies cleanly across releases - and will fail loudly the moment a release ships its own submodule of this name, which is the signal to drop it.
Rewrote environment_indicator_access.feature and added a computed-style Behat step. The previous scenario asserted the element existed and carried a style attribute, which passed for the entire period the indicator was invisible. The new assertions compare a computed value that differs by role - 8px for a site administrator against 0px for a content author on the same selector - and assert the legacy strip is gone. These cover rendered output, so they hold regardless of where the implementation lives.

Navigation support is tracked upstream at #3457688 but ships in no release: the GitLab API confirms modules/ on both 4.x and 5.0.x contains only environment_indicator_toolbar and environment_indicator_ui, and drush pm:list on 4.0.25 discovers only those two submodules. MR !86 targets 4.x but is written against a pre-4.0.25 tree and no longer applies; MR !141 indents the strip past the sidebar horizontally, which does not help because the top bar covers it vertically across the full width. Note that the upstream design renders a named button rather than a stripe, so the two are not visually equivalent.

Screenshots

Sidebar detail, zoomed - the 8px environment stripe on the inline-start edge:

Full page, showing the site header now flush under the top bar:

Before / After

BEFORE                                    AFTER

y=0  ┌─────────────────────────────┐      y=0  ┌─────────────────────────────┐
     │ #environment-indicator      │           │▓ .top-bar      z-index: 490 │
     │   static, z-index: 10, h=28 │           │▓                            │
     │   ...covered, never seen    │      y=64 ├▓────────────────────────────┤
y=0  │ .top-bar       z-index: 490 │           │▓ .ct-header  (flush at 64)  │
     │   fixed, paints over it     │           │▓                            │
y=64 ├─────────────────────────────┤           │▓                            │
     │                             │           │▓                            │
     │   28px dead band            │           ▓ = 8px stripe on .admin-toolbar
     │                             │               border-inline-start,
y=92 ├─────────────────────────────┤               coloured from bg_color
     │ .ct-header  (pushed to 92)  │
     │                             │


.ct-header top: 92px                      .ct-header top: 64px
#environment-indicator: present, unseen   #environment-indicator: removed
favicon: environment-coloured             favicon: environment-coloured (preserved)


PACKAGING

  composer.json
    └── extra.patches
          └── drupal/environment_indicator
                └── patches/environment-indicator-navigation.patch
                      │
                      │ creates (add-only, -p1)
                      ▼
  web/modules/contrib/environment_indicator/
    └── modules/
          ├── environment_indicator_navigation/   ← this patch
          │     ├── .info.yml   (deps: environment_indicator, navigation)
          │     ├── .libraries.yml
          │     ├── .module     (page_attachments, preprocess_html)
          │     ├── css/navigation.css
          │     └── README.md
          ├── environment_indicator_toolbar/      ← shipped
          └── environment_indicator_ui/           ← shipped

  When a release ships its own environment_indicator_navigation,
  the add-only patch fails to apply and the build stops - the
  signal to drop the patch.

…sidebar.

coderabbitai · 2026-07-30T07:26:53Z

📝 Walkthrough

Walkthrough

The do_base module now integrates the environment indicator with the navigation sidebar using conditional library attachment, CSS variables, and border styling. HTML preprocessing removes the full-width indicator markup while preserving related attachments and cache metadata. Unit and Behat tests cover eligibility and role-specific rendering.

Changes

Environment indicator integration

Layer / File(s)	Summary
Indicator assets and attachment hook `web/modules/custom/do_base/src/Hook/EnvironmentIndicatorHook.php`, `web/modules/custom/do_base/css/*`, `web/modules/custom/do_base/do_base.libraries.yml`	Adds conditional environment indicator library attachment based on module availability, permissions, and active environment configuration. Defines sidebar border styling using CSS variables.
HTML preprocessing and render cleanup `web/modules/custom/do_base/src/Hook/EnvironmentIndicatorHook.php`	Adds the environment color CSS variable and retains only indicator attachments and cache metadata while removing the full-width indicator markup.
Indicator behavior validation `web/modules/custom/do_base/tests/src/Unit/EnvironmentIndicatorHookTest.php`, `tests/behat/bootstrap/FeatureContext.php`, `tests/behat/features/environment_indicator_access.feature`	Tests applicability, cacheability, HTML output, render-array handling, computed styles, and administrator/content-author scenarios.

Estimated code review effort: 3 (Moderate) | ~25 minutes

Sequence Diagram(s)

sequenceDiagram
  participant DrupalPage
  participant EnvironmentIndicatorHook
  participant ModuleHandler
  participant Account
  participant EnvironmentConfig
  participant HtmlOutput
  DrupalPage->>EnvironmentIndicatorHook: invoke pageAttachments
  EnvironmentIndicatorHook->>ModuleHandler: check required modules
  EnvironmentIndicatorHook->>Account: check required permissions
  EnvironmentIndicatorHook->>EnvironmentConfig: read active environment
  EnvironmentIndicatorHook->>DrupalPage: attach library and cache metadata
  DrupalPage->>EnvironmentIndicatorHook: invoke preprocessHtml
  EnvironmentIndicatorHook->>HtmlOutput: append color CSS variable
  EnvironmentIndicatorHook->>HtmlOutput: retain indicator attachments and cache metadata

🚥 Pre-merge checks | ✅ 5

✅ Passed checks (5 passed)

Check name	Status	Explanation
Linked Issues check	✅ Passed	The changes implement the requested Navigation module integration and show the environment as a colored sidebar stripe.
Out of Scope Changes check	✅ Passed	The modifications are limited to the sidebar stripe feature, its CSS, hook wiring, and tests; no unrelated scope stands out.
Docstring Coverage	✅ Passed	No functions found in the changed files to evaluate docstring coverage. Skipping docstring coverage check.
Description Check	✅ Passed	Check skipped - CodeRabbit’s high-level summary is enabled.
Title check	✅ Passed	The title clearly summarizes the main change: integrating the environment indicator as a visual element in Drupal’s Navigation sidebar.

✨ Finishing Touches

📝 Generate docstrings

Create stacked PR
Commit on current branch

🧪 Generate unit tests (beta)

Create PR with unit tests
Commit unit tests in branch feature/270-env-indicator-nav

_{Comment @coderabbitai help to get the list of available commands.}

codecov-commenter · 2026-07-30T07:28:22Z

Codecov Report

✅ All modified and coverable lines are covered by tests.
✅ Project coverage is 89.16%. Comparing base (c6c0c34) to head (1756fb6).

Additional details and impacted files

@@           Coverage Diff            @@
##           develop     #274   +/-   ##
========================================
  Coverage    89.16%   89.16%
========================================
  Files           15       15
  Lines          203      203
========================================
  Hits           181      181
  Misses          22       22

☔ View full report in Codecov by Harness.
📢 Have feedback on the report? Share it here.

🚀 New features to boost your workflow:

❄️ Test Analytics: Detect flaky tests, report on failures, and find test suite problems.
📦 JS Bundle Analysis: Save yourself from yourself by tracking and limiting bundle sizes in JS merges.

…ndicator' submodule.

github-actions · 2026-07-30T23:28:43Z

Code coverage (threshold: 80%)

  Classes: 50.00% (7/14)
  Methods: 73.33% (22/30)
  Lines:   93.21% (357/383)

Per-class coverage

Drupal\do_content_api\EventSubscriber\JsonApiWriteGateSubscriber
  Methods:  66.67% ( 2/ 3)   Lines:  88.89% (  8/  9)
Drupal\do_content_api\Hook\EntityCreateAccessHook
  Methods: 100.00% ( 1/ 1)   Lines: 100.00% (  9/  9)
Drupal\do_content_api\Hook\ModerationPolicyHook
  Methods:  50.00% ( 1/ 2)   Lines:  93.75% ( 15/ 16)
Drupal\do_content_api\Routing\RouteSubscriber
  Methods: 100.00% ( 1/ 1)   Lines: 100.00% (  6/  6)
Drupal\do_feed\FeedUrlBuilder
  Methods: 100.00% ( 4/ 4)   Lines: 100.00% ( 18/ 18)
Drupal\do_feed\Form\FeedSettingsForm
  Methods: 100.00% ( 4/ 4)   Lines: 100.00% ( 15/ 15)
Drupal\do_feed\Hook\EntityDeleteHook
  Methods:  50.00% ( 1/ 2)   Lines:  92.31% ( 12/ 13)
Drupal\do_feed\Hook\EntityPresaveHook
  Methods: 100.00% ( 4/ 4)   Lines: 100.00% ( 54/ 54)
Drupal\do_feed\Hook\PreprocessParagraphHook
  Methods: 100.00% ( 2/ 2)   Lines: 100.00% ( 14/ 14)
Drupal\do_feed\Hook\PreprocessViewsViewRowRssHook
  Methods: 100.00% ( 1/ 1)   Lines: 100.00% (  3/  3)
Drupal\do_feed\Hook\ViewsPreViewHook
  Methods:  50.00% ( 1/ 2)   Lines:  96.43% ( 27/ 28)

AlexSkrypnyk added 3 commits July 30, 2026 16:57

[#270] Showed the environment as a coloured stripe on the Navigation …

aafd77d

…sidebar.

[#270] Carried the indicator cache metadata over with its attachments.

74afe07

[#270] Aligned the hook and its test with the project code style.

026001c

github-actions Bot assigned AlexSkrypnyk Jul 30, 2026

AlexSkrypnyk added A1 Board worker 1 AUTOMERGE Pull request has been approved and set to automerge labels Jul 30, 2026

This comment has been minimized.

Sign in to view

AlexSkrypnyk added the Needs review Pull request needs a review from assigned developers label Jul 30, 2026

AlexSkrypnyk temporarily deployed to PR-274 July 30, 2026 07:36 Inactive

[#270] Moved the Navigation integration into a patched 'environment_i…

1756fb6

…ndicator' submodule.

AlexSkrypnyk changed the title ~~[#270] Showed the environment as a coloured stripe on the Navigation sidebar.~~ [#270] Added a patched 'environment_indicator_navigation' submodule showing the environment on the Navigation sidebar. Jul 30, 2026

AlexSkrypnyk deployed to PR-274 July 30, 2026 23:46 View deployment

AlexSkrypnyk merged commit 44cae56 into develop Jul 30, 2026
14 of 15 checks passed

AlexSkrypnyk deleted the feature/270-env-indicator-nav branch July 30, 2026 23:59
